High-Performance 12MP Autofocus Camera Module for Raspberry Pi
Upgrade your Raspberry Pi projects with the high-resolution 12MP Sony IMX708 Sensor. Designed for machine vision, robotics, and smart home applications, this module offers advanced Phase Detection Autofocus (PDAF), High Dynamic Range (HDR) support, and exceptional low-light clarity.
Key Features:
- 12MP Sony IMX708 Sensor: Delivering crisp image resolution up to 4608x2592 pixels.
- Fast & Precise Autofocus: I2C controlled phase detection autofocus for sharp images at any distance.
- Multiple Lens Options: Available in Standard (75° FOV) and Ultra-Wide (120° FOV) versions.
- Night Vision (NoIR) Options: Infrared-sensitive variants available for low-light or night-time monitoring.
- Compact Size Options: Choose between Standard (25x25mm) and Mini (16x25mm) form factors.
- Full Raspberry Pi Compatibility: Works with all Raspberry Pi boards (Pi 5, Pi 4, Zero, Zero 2 W with adapter cable). Includes 16cm 22PIN flex ribbon cable.
Technical Specifications:
| Sensor | Sony IMX708 |
| Resolution | 12 Megapixels (4608 x 2592) |
| Pixel Size | 1.4µm x 1.4µm |
| Focusing Method | I2C Controlled Autofocus |
| FOV (Diagonal) | 75° (Standard) / 120° (Wide) |
| Aperture | F1.8 (Standard) / F2.2 (Wide) |
| Focal Length | 4.74mm (Standard) / 2.75mm (Wide) |
| HDR Support | Yes |
| Dimensions | 25x25mm (Standard) / 16x25mm (Mini) |
